    Professional 5 Strips Razor Barbed Wire Machine 2.2KW 1325*990*2140mm

    Ask Lasest Price
    Brand Name : DIAOZHUO
    Model Number : DZ005 DZ009 DZ011 DZ021
    Certification : CE ISO9001
    Payment Terms : T/T, D/P, L/C
    Supply Ability : 30 sets per month
    Delivery Time : 20-30 days
    Price : variable
    • Product Details
    • Company Profile

    Professional 5 Strips Razor Barbed Wire Machine 2.2KW 1325*990*2140mm

    5 strips razor barbed wire punching machine fully automatic


    razor wire machine


    Razor barbed wire machine,is specially used to manufacture razor barbed wires.It mainly consists of punching razor strip machine,coiling wire machine and mould.The punching razor strip machine is used as punching the outside razor strip of razor wire .The coiling wire machine is used as coiling the wire into the razor strip to form the finished razor wire.The mould decide the razor length ,width the space.


    Punching machine


    punching Plate thickness0.3-0.6mm
    punching Plate width99-145mm
    punching Production speed60-75times/min
    Motor power2.2KW
    Rated voltage380V 50HZ
    Weight1.9T
    Overall dimension1325*990*2140mm

    Coiling machine

    Voltage380V, 50Hz,or client’s required voltage
    Power1.5kw
    Producing speed80Kg/h
    Wire diameter2.5mm
    Weight300Kg
    Dimension

    1100mm×750mm×1200mm


    Mould type

    Mould typeBarb LengthBarb widthBarb spacing
    R112±1mm13±1mm26±1mm
    R212±1mm15±1mm26±1mm
    R318±1mm15±1mm33±1mm
    R422±1mm15±1mm34±1mm
    R528±1mm15±1mm34±1mm
    R630±1mm18±1mm34±1mm
    R760±1mm32±1mm96±1mm
    R865±1mm21±1mm100±1mm
