6x8 gabion mesh gabion box making machine, 8x10 gabion mesh weaving
machine
1, my machine advantage and after sales service:
a. material of the machine we all buy from the China biggest steel
factory
b, welding process we all use modern and high efficiency machine
c, cutting process we all make sure the size exactly and minimum
error
d, collection process we all use assembly line works
e, paint and surface workers all have rich experiences
f, motor of machine we use first-class China strand
g, every machine we will offer spares freely, these spares can be
enough for using one year
h, if machine broken during worker and in the guarantee time, we
will offer spares freely
i, we will offer the guarantee time 2 or 3 years , this is double
or three time of other factories
2, machine details
Model
| Mesh Size(mm) | Max. Width(mm) | Wire diameter(mm) | Twisting Number | Main Drive Shaft Speed(r/min) | Motor Capacity(KW) | Theoretical Speed(m/h) |
| LNWL23-60-2 | 60*80 | 2300 | 1.6-3.0 | 3 | 25 | 11 | 165 |
| LNWL23-80-2 | 80*100 | 1.6-3.0 | 195 |
| LNWL23-100-2 | 100*120 | 1.6-3.5 | 225 |
| LNWL23-1200-2 | 120*150 | 1.6-3.2 | 20 | 255 |
| LNWL33-60-2 | 60*80 | 3300 | 1.6-2.8 | 25 | 15 | 165 |
| LNWL33-80-2 | 80*100 | 1.6-3.0 | 195 |
| LNWL33-100-2 | 100*120 | 1.6-3.2 | 225 |
| LNWL33-120-2 | 120*150 | 1.6-3.5 | 20 | 255 |
| LNWL43-60-2 | 60*80 | 4300 | 1.6-2.8 | 25 | 22 | 165 |
| LNWL43-80-2 | 80*100 | 1.6-3.0 | 195 |
| LNWL43-100-2 | 100*120 | 1.6-3.0 | 225 |
| LNWL43-120-2 | 120*150 | 1.6-3.2 | 20 | 255 |
| LNWL43-60-3 | 60*80 | 4300 | 1.6-2.8 | 5 | 25 | 2 | 165 |
| LNWL43-80-3 | 80*100 | 1.6-3.0 | 195 |
| LNWL43-100-3 | 100*!20 | 1.6-3.0 | 225 |
| LNWL43-120-3 | 120*150 | 1.6-3.2 | 20 | 255 |
3, FAQ
Q, how long your machine guarantee time?
A, we all supply 3 years guarantee time for every clients. this is
much longer than other factory,
Q, if you have engineer can help me about the install?
A, sure, we have 3 engineers to do this work only every year, their
work is go abroad to help the clients about the install work and
train workers how to operate well of my machines
Q, can i visit your factory?
A,sure and welcome. actually we will invit every client to come to
visit my factory when we finish the machines for them, so they can
check their machines together. this is the best way to build the
trust and long time business friendship between us
